The azygos lobe: An unusual anatomical entity with unusual cases

Authors

Abstract

The knowledge of azygos lobe is important during thoracic surgical procedures. It is a rare anomaly in bronchopulmonary segmentation due to an unusual course of the azygos vein. There is no pathological sense alone; if combined with other pathological events, it should be considered. We aimed to emphasize in this article the formation of the azygos lobe with described together pathologies in the literature.

Keywords

The azygos lobe was first described by Wrisberg in 1778.^1,2 The incidence of azygos lobe is 0.1 to 1.1% in autopsy series, and 0.01 to 2.6% in radiographic series.^1,3 It is more frequent on the right side (Figure 1, Figure 2). An azygos lobe is formed when a precursor of the azygos vein fails to migrate over the apex of the lung during fetal life. The azygos lobe is not a true lobe or accessory lobe because it is not made up of specific bronchopulmonary segments but is formed of varying proportions of 1 or 2 segments of the right upper lobe.⁴ Embryologically, a part of the upper lobe of the right lung may come to lie medial to the azygos vein; this part is called the azygos lobe.⁵
The azygos venous system represents an accessory venous pathway supplying an important collateral circulation between the superior and inferior vena cava.⁶ Between the 4th and 6th week of embryonic development, the 4th to the 11th intercostal veins drain into the right supracardinal vein, which will form, with the terminal portion of the posterior cardinal vein.¹ The azygos lobe is the result of a defect of medial sliding of the azygos vein towards the right tracheobronchial junction above the apex of the developing lung.^1,3 On the basis of Fleischner’s experience, the azygos vein, normally measuring about 0.9 cm, can be seen in 75% of normal chest X-rays.^6,7 The azygos system is a paired paravertebral venous pathway in the posterior thorax. It originates at the junction of the right ascending lumbar and subcostal veins, entering through the aortic hiatus. It ascends along the anterolateral surface of the thoracic vertebrae and arches ventrally to the right main bronchus at T5–T6, draining into the SVC. It drains into the right brachiocephalic vein, right subclavian vein, intrapericardial SVC, or right atrium more rarely.^6,8
Variations in the azygos system rarely cause symptoms.⁶ An azygos lobe is not susceptible to disease. However, multiple authors have reported spontaneous pneumothorax associated with the azygos lobe in adult and pediatric patients. These reports include: azygos lobe without azygos vein as a sign of previous iatrogenic pneumothorax;⁹ pneumothorax and mediastinal emphysema due to an air leak from a bulla in an azygos lobe;¹⁰ thoracoscopic management of spontaneous pneumothorax due to azygos lobe bullae;¹¹ and spontaneous pneumothorax in a patient with an azygos lobe.¹² The association of an azygos lobe and spontaneous pneumothorax has been rarely reported. There has been speculation that an azygos lobe might have a protective effect against the development of spontaneous pneumothorax. Three mechanisms were proposed: the reflected pleura might be adherent, limiting the size of a potential pneumothorax that would be less easily recognized clinically; the mesoazygos might lessen the mechanical stresses transmitted to the apex of the lung; or the altered anatomy might actually protect against bullae formation.^11,12 Physiologically, there is decreased perfusion and ventilation of the azygos lobe on nuclear studies, thus it is relatively under-inflated. The anatomical explanation for the decreased ventilation is distortion of the bronchi due to bending or kinking by the azygos fissure. On the other hand, this same distortion in bronchial anatomy could predispose the azygos lobe to air trapping with subsequent evolution of emphysema, bronchiectasis, or atelectasis.¹¹
Some diseases reported in the literature regarding the azygos lobe include azygos lobe associated with esophageal atresia⁴ and concomitant occurrence of tracheal bronchus, pulmonary sequestration, and azygos lobe.¹³ Tracheal bronchus, pulmonary sequestration, and azygos lobes are rare congenital anomalies of the lungs, although they may occur along with various anomalies involving the thoracic cavity.¹³
Azygos lobe-related tumors are also defined in the literature. These include superior sulcus tumor arising in an azygos lobe,¹⁴ azygos lobe small cell carcinoma,¹⁵ and adenocarcinoma arising in an azygos lobe.¹⁶ Superior sulcus tumors usually arise in the apex of the lung and may invade the brachial plexus, the subclavian vessels, the second and third ribs, the stellate ganglion, and adjacent vertebral bodies.¹⁴ The presence of an azygos lobe is assumed to be of little clinical significance. However, neither the surgical/oncological implication of having a tumor confined to an azygos lobe, nor the reasons for rarity of cancer development in this lobe, is known, despite its being a common anatomical variant. One theory hypothesizes that this rarity of cancer development results from decreased ventilation of the azygos lobe.¹⁶ While this is a controversial assumption, the ventilation of an azygos lobe may be relatively limited due to constriction by the azygos vein, possibly resulting in less oxygen delivery and particle deposition of carcinogens, thereby restricting carcinogenesis within this lobe despite its apparent segmental or subsegmental bronchovascular supply.¹⁶
In conclusion, the knowledge of the azygos lobe is important during thoracic surgical procedures. It is a rare anomaly in bronchopulmonary segmentation due to an unusual course of the azygos vein. There is no pathological significance alone, but if combined with other pathological events, it should be considered.

Declarations

References

1. Ndiaye A, Ndiaye NB, Ndiaye A, et al. The azygos lobe: an unusual anatomical observation with pathological and surgical implications. Anat Sci Int. 2012;87:174-178. doi:10.1007/s12565-011-0119-5
   Article PubMed Google Scholar
2. Cairney J. The lobe of the azygos vein. J Anat. 1923;58:54-58.
   PubMed Google Scholar
3. Chiba S, Suzuki T, Takahashi D, Kasai T. An autopsy case of azygos lobe and the extrapulmonary course of the bronchial veins in man. Okajimas Folia Anat Jpn. 1990;86(6):313-338. doi:10.2535/ofaj1936.66.6_313
   Article PubMed Google Scholar
4. Eradi B, Cusick E. Azygos lobe associated with esophageal atresia: a trap for the unwary. J Pediatr Surg. 2005;40:E11-E12. doi:10.1016/j.jpedsurg.2005.07.032
   Article PubMed Google Scholar
5. Salve VT, Atram JS, Mhaske YV. Azygos lobe presenting as right paratracheal shadow. Lung India. 2015;32(1):85-86. doi:10.4103/0970-2113.148463
   Article PubMed Google Scholar
6. Piciucchi S, Barone D, Sanna S, et al. The azygos vein pathway: an overview from anatomical variations to pathological changes. Insights Imaging. 2014;5:619-628. doi:10.1007/s13244-014-0351-3
   Article PubMed Google Scholar
7. Fleischner FG, Udis SW. Dilatation of the azygos vein: a roentgen sign of venous engorgement. Am J Roentgenol. 1952;67:569-575.
   PubMed Google Scholar
8. Dudiak CM, Olson MC, Posniak HV. CT evaluation of congenital and acquired abnormalities of the azygos system. Radiographics. 1991;11:233-246. doi:10.1148/radiographics.11.2.2028062
   Article PubMed Google Scholar
9. Betschart T, Goerres GW. Azygos lobe without azygos vein as a sign of previous iatrogenic pneumothorax: two case reports. Surg Radiol Anat. 2009;31:559-562. doi:10.1007/s00276-009-0479-x
   Article PubMed Google Scholar
10. Internullo E, Migliore M. Pneumothorax and mediastinal emphysema due to an air leak from a bulla in an azygos lobe. Eur J Cardiothorac Surg. 2005;28:641. doi:10.1016/j.ejcts.2005.06.045
    Article PubMed Google Scholar
11. Azoury FM, Sayad P. Thoracoscopic management of spontaneous pneumothorax due to azygos lobe bullae. Asian Cardiovasc Thorac Ann. 2011;19:427-429. doi:10.1177/0218492311420542
    Article PubMed Google Scholar
12. Sadikot RT, Cowen ME, Arnold AG. Spontaneous pneumothorax in a patient with an azygos lobe. Thorax. 1997;52:579-580. doi:10.1136/thx.52.6.579
    Article PubMed Google Scholar
13. Arslan S, Sabancıoğulları V, Akkurt İ. Concomitant occurrence of tracheal bronchus, pulmonary sequestration and azygos lobe. Turk Gogus Kalp Damar Cerrahisi Derg. 2013;21(2):506-509. doi:10.5606/tgkdc.dergisi.2013.4755
    Article PubMed Google Scholar
14. Delalieux S, Hendriks J, Valcke Y, et al. Superior sulcus tumor arising in an azygos lobe. Lung Cancer. 2006;54:255-257. doi:10.1016/j.lungcan.2006.07.004
    Article PubMed Google Scholar
15. Sen S, Barutca S, Meydan N. Azygos lobe small cell carcinoma. Eur J Cardiothorac Surg. 2004;26:1041. doi:10.1016/j.ejcts.2004.07.041
    Article PubMed Google Scholar
16. Fukuhara S, Montgomery M, Reyes A. Robot-assisted azygos lobectomy for adenocarcinoma arising in an azygos lobe. Interact Cardiovasc Thorac Surg. 2013;16:715-717. doi:10.1093/icvts/ivt021
    Article PubMed Google Scholar

Figures

View Fullscreen

Figure 1. Posteroanterior chest X ray: showing an azygos vein

View Fullscreen

Figure 2. Chest computed tomography: showing an azygos lobe
